BOSCH REXROTH
R901186327

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HED 5 OH-3X/200K14V (R901186327) is a high-precision piston type pressure switch designed for versatile applications requiring reliable pressure monitoring and control. It features a bar micro switch with both normally closed (NC) and normally open (NO) contact functions, allowing for potential-free switching of currents ranging from milliamps to 0.5A. This flexibility makes it suitable for diverse electrical requirements. The device boasts a small hysteresis, ensuring accuracy depending on the set switching point, and offers high repetition accuracy that is less than 1% of the set pressure. The durability of the HED 5 OH-3X/200K14V is enhanced by FKM seals that provide resistance against various hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, and HFDR. Its robust design includes a flange connection for secure mounting and a maximum pressure rating of 315 bar. The electrical connection is facilitated via a large cubic connector that is DIN EN compliant with a 3-pole+PE configuration. This unit does not come with a mating connector but adheres to international standards such as CE according to the Low Voltage Directive EU. The supply voltage range for this pressure switch is between 24 to 240 V AC/DC, which accommodates various power supplies. Weighing in at approximately 0.6 kg, it's designed to integrate seamlessly into hydraulic systems without adding significant weight or bulk. Overall, the Bosch Rexroth HED 5 OH-3X/200K14V provides reliable performance in controlling and monitoring hydraulic pressures in various applications while ensuring compliance with several international safety and quality standards such as CE, CCC, and UL certifications.
