BOSCH REXROTH
R978916304
$1,301.00
- BOSCH REXROTH
- Material:R978916304
- Model:H-4WH 22 E7X/S2
Due to extremely high demand, please call 920-337-0234 for availability
Size 22, symbol E, electrical with solenoid
Industrial hydraulic valve in a high performance range. Reliable switching of the oil flow direction according to hydraulic symbol.
Unpacked Weight: 11.3 kg
Valve type H-WH is a directional spool valve with hydraulic actuation. It controls the start, stop and direction of a flow. The directional valve basically consists of the valve housing (1), the main control spool (2), one or two return springs (3.1) and (3.2) at valves with spring return or spring centering as well as the diversion plate (11). The main control spool (2) is actuated directly by pressurization. The main control spool (2) is held in zero or initial position by springs or pressurization. Pilot oil supply and return are external (see pilot oil supply).
4/3 directional valve with spring centering of the control spool
With this version, the main control spool (2) is held in zero position by two return springs (3.1) and (3.2). The two spring chambers (6) and (8) are connected to ports X and Y via the diversion plate (11). With pilot pressure loading of one of the two front sides of the main control spool (2), the spool is moved to the switching position. In the valve, the required ports are connected in this way. The spring on the opposite side returns the spool to the zero or initial position at pressure relief of the pressurized control spool area.
Pilot oil supply (schematic illustration)
NG10
Pilot oil supply (schematic illustration)
NG16
Pilot oil supply (schematic illustration)
NG25 („W.H 22“)
Pilot oil supply (schematic illustration)
NG25 („W.H 25“)
Pilot oil supply (schematic illustration)
Size 32
Pilot oil supply |
Pilot oil return |
||
External |
2, 3 closed |
External |
1 closed |
Internal |
2, 3 open |
Internal |
1 open |
1 |
Plug screw M6 according to DIN 906, wrench size 3 - Pilot oil return |
2 |
Plug screw M6 according to DIN 906, wrench size 3 - Pilot oil supply |
3 |
Plug screw M12 x 1.5 according DIN 906, wrench size 6 |
Type H-WH…
The pilot oil supply and return is implemented externally via channel X and Y.
External pilot oil supply, external pilot oil return |
Spool valve |
Pilot-operated |
Size 10 … 32 |
Maximum operating pressure 350 bar |
Maximum flow 1100 l/min |
Component series 4X, 7X, 6X |
Data Sheet | Download Data Sheet |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Spool symbol | Symbol E |
Max. pressure | 350 |
Productgroup ID | 9,10,11,12,13,14 |
Number of ports | 4 |
Type of actuation | with solenoid actuation |
Size | 22 |
Max. flow | 450 |
Type of connection | Subplate mounting |
Connection diagram NFPA | NFPA T3.5.1 R2-2002 D08 |
Size_CETOP | 0 |
Connection diagram | ISO 4401-08-08-0-05 |
Number of switching positions | 3 |
Weight | 11.3 |
Seals | NBR |
Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
01 |
02 |
03 |
04 |
05 |
06 |
07 |
08 |
09 |
10 |
11 |
12 |
13 |
14 |
15 |
||
H – |
WH |
/ |
/ |
* |
01 |
Up to 350 bar |
H - |
02 |
3-way version |
3 |
4-way version |
4 |
|
Type of actuation |
||
03 |
hydraulic |
WH |
Size |
||
04 |
NG10 |
10 |
NG16 |
16 |
|
NG25 (version "H-WH 22") |
22 |
|
NG25 (version "H-WH 25") |
25 |
|
Size 32 |
32 |
|
Spool return in the main valve |
||
05 |
by means of springs |
no code |
hydraulic 1) |
H |
|
06 |
Symbols; for the possible version, see "Symbols/Circuit diagrams" |
|
07 |
Component series 40 … 49 (40 … 49: unchanged installation and connection dimension) – NG10 |
4X |
Component series 60 … 69 (60 … 69: unchanged installation and connection dimension) – NG25 ("H-WH 25") and NG32 |
6X |
|
Component series 70 … 79 (70 … 79: unchanged installation and connection dimension) – NG16 (from series 72) andNG25 ("H-WH 22") |
7X |
|
Pilot oil flow |
||
08 |
External pilot oil supply, external pilot oil return 2) |
no code |
Switching time adjustment |
||
09 |
without switching time adjustment |
no code |
Switching time adjustment as supply control |
S |
|
Switching time adjustment as discharge control |
S2 |
|
Corrosion resistance (outside) |
||
10 |
None (valve housing primed) |
no code |
Improved corrosion protection (240 h salt spray test according to EN ISO 9227) |
J3 |
|
Spool position monitoring |
||
11 |
Without position switch |
no code |
Monitored spool position “a” |
QMAG24 |
|
Monitored spool position “b” |
QMBG24 |
|
monitored spool position "a" and "b" |
QMABG24 |
|
Monitored rest position |
QM0G24 |
|
Stroke setting |
||
12 |
For ordering code, see dimesnions |
|
preload valve (not for NG10) 2) |
||
13 |
without pressure reducing valve |
no code |
with pressure reducing valve |
D3 |
|
Seal material |
||
14 |
NBR seals |
no code |
FKM seals |
V |
|
Observe compatibility of seals with hydraulic fluid used. (Other seals upon request) |
||
15 |
Further details in the plain text |
* |
1) – 2 spool positions (hydraulic end position): only symbols C, D, K, Z, Y | |
– 3 switching positions (hydraulically centered): only NG16, NG25 ("4W.H 25") and NG32 | |
2) Pilot oil supply X or return Y external: | |
– Minimum pilot pressure: please observe Technical data! | |
– Maximum pilot pressure: please observe Technical data! | |
general
Size |
10 | 16 | 25 (H-WH22) | 25 (H-WH25) | 32 | ||
Weight (approx.) |
Valve witch hydraulic actuation (type WH...) |
kg |
5.5 | 7.3 | 10.5 | 16.5 | 39.5 |
Switching time adjustment "S" and "S2" |
kg |
0.8 | |||||
Pressure reducing valve "D3" |
kg |
0.4 | |||||
Installation position |
Any; horizontal with valves with hydraulic control spool return "H" and symbol A, B, C, D, K, Z, Y. With suspended installation, higher sensitivity to contamination – horizontal is recommended. | ||||||
Ambient temperature range |
Standard version |
°C |
-20 … +70 | ||||
Storage temperature range |
°C |
+5 … +40 | |||||
Surface protection |
Valve body |
Coating, layer thickness max. 100 μm | |||||
MTTFD values according to EN ISO 13849 |
Years |
150 |
hydraulic
Size |
10 | 16 | 25 (H-WH22) | 25 (H-WH25) | 32 | |||
Maximum operating pressure |
Port P |
bar |
350 | |||||
Port A |
bar |
350 | ||||||
Port B |
bar |
350 | ||||||
Port T |
External pilot oil return Y |
bar |
315 | 250 | ||||
Port Y |
Pilot oil return, external |
bar |
250 | 210 | 250 | |||
Hydraulic fluid |
see table | |||||||
Hydraulic fluid temperature range |
NBR seals |
°C |
-20 … +80 | |||||
FKM seals 1) |
°C |
-15 … +80 | ||||||
HFC hydraulic fluid |
-20 … +50 °C | |||||||
Viscosity range |
mm²/s |
2.8 … 500 | ||||||
Maximum admissible degree of contamination of the hydraulic fluid 2) |
Class 20/18/15 according to ISO 4406 (c) | |||||||
Maximum pilot pressure 3) |
bar |
250 | 210 | 250 | ||||
Minimum pilot pressure |
Pilot oil supply X external or internal (with symbols D, K, E, J, L, M, Q, R, U, W) |
3-spool position valve, spring-centered |
bar |
12 | 14 | 12.5 | 13 | 8.5 |
2-spool position valve, spring end position |
bar |
10 | 14 | 13 | 10 | |||
Pilot volume for switching process |
3-spool position valve, spring-centered |
cm³ |
2.04 | 5.72 | 7.64 | 14.2 | 29.4 | |
2-spool position valve |
cm³ |
4.08 | 11.45 | 15.28 | 28.4 | 58.8 | ||
3-spool position valve, pressure-centered |
from zero position in switching position “a” |
cm³ |
- | 2.83 | - | 7.15 | 14.4 | |
from switching position “a” in zero position |
cm³ |
- | 5.72 | - | 14.18 | 29.4 | ||
from zero position in switching position “b” |
cm³ |
- | 5.72 | - | 14.18 | 29.4 | ||
from switching position “b” in zero position |
cm³ |
- | 8.55 | - | 19.88 | 43.8 | ||
Pilot flow for shortest switching time, approx. |
l/min |
35 | 45 |
1) | If type WH is used in potentially explosion-proof areas, see data sheet 07011. |
2) | The cleanliness classes specified for the components must beadhered to in hydraulic systems. Effective filtration prevents faults and simultaneously increases the life cycle of the components. |
3) | External pilot oil supply:In connection with version "H-", compliance with the maximum pilot pressure must be ensured by appropriate measures (e. g. protection of the separate pilot oil circuit bymeans of a pressure relief valve)! |
Free flow cross-sections in zero position with spools Q, V and W
Size |
10 | 16 | 25 (H-WH22) | 25 (H-WH25) | 32 | ||
Spool Q |
A – T; B – T |
mm² |
13 | 32 | 78 | 83 | 78 |
Spool V |
P – A |
mm² |
13 | 32 | 73 | 83 | 73 |
A – T; B – T |
mm² |
13 | 32 | 84 | 83 | 84 | |
Spool W |
A – T; B – T |
mm² |
2.4 | 6 | 10 | 14 | 20 |
Hydraulic fluid |
Classification |
Suitable sealing materials |
Standards |
Data sheet |
|
Mineral oil |
HL, HLP, HLPD, HVLP, HVLPD |
NBR, FKM |
DIN 51524 |
90220 |
|
Bio-degradable |
Insoluble in water |
HETG |
FKM |
ISO 15380 |
90221 |
HEES |
FKM |
||||
Soluble in water |
HEPG |
FKM |
ISO 15380 |
||
Flame-resistant |
Water-free |
HFDU (glycol base) |
FKM |
ISO 12922 |
90222 |
HFDU (ester base) |
FKM |
||||
HFDR |
FKM |
Important notice on hydraulic fluids:
For more information and data on the use of other hydraulic fluids, please refer to the data sheets above or contact us. There may be limitations regarding the technical valve data (temperature, pressure range, life cycle, maintenance intervals, etc.). The ignition temperature of the hydraulic fluid used must be 50 K higher than the maximum solenoid surface temperature.
• Bio-degradable and flame-resistant:
If these hydraulic fluids are used, small amounts of dissolved zinc may get into the hydraulic system (700 mg zinc per pole tube).
Inductive position switch type QM: electrical connection
The electric connection is realized via a 4-pole mating connector (separate order) with connection thread M12 x 1.
electrical
Connection voltage (DC voltage) |
V |
24 | ||
Voltage tolerance (connection voltage) |
+30 %/-15 % | |||
Admissible residual ripple |
% |
≤ 10 | ||
Max. load capacity |
mA |
400 | ||
Switching outputs |
PNP transistor outputs, load between switching outputs and GND | |||
Pinout |
1 |
V |
24 | |
2, 4 |
Switching output |
mA |
400 | |
3 |
Earthing (GND) |
V |
0 |
For applications outside these parameters, please consult us!
(measured with HLP46, ϑOil = 40 °C ±5 °C)
NG10
Δp-qV characteristic curves
Symbol |
Spool position |
Zero position |
|||||
P – A |
P – B |
A – T 1) |
B – T 1) |
A – T |
B – T |
P – T |
|
E, Y, D, Q, V, W, Z |
1 |
1 |
3 |
5 |
|||
F |
1 |
3 |
1 |
4 |
3 |
– |
6 |
G, T |
4 |
2 |
4 |
7 |
– |
– |
8 |
H, C |
3 |
3 |
1 |
7 |
1 |
5 |
5 |
J, K |
1 |
2 |
1 |
6 |
|||
L |
2 |
2 |
1 |
4 |
2 |
– |
– |
M |
3 |
3 |
2 |
5 |
|||
P |
3 |
1 |
2 |
5 |
– |
5 |
7 |
R |
1 |
2 |
3 |
– |
|||
U |
2 |
2 |
3 |
6 |
– |
6 |
– |
A, B |
2 |
2 |
– |
– |
1) | The pressure differential refers to the use of port T. If port T1 is additionally used, the pressure differential maybe lower. If only port T1 is used, the relations A – T and B – T may be reversed. |
Performance limits: (measured with HLP46, ϑOil = 40 °C ±5 °C)
NG10
2-spool position valve – qV maxin l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring end position in the main valve1) (with ppilot min = 12 bar) |
|||||
C, D, K, Y, Z |
160 |
160 |
160 |
160 |
160 |
X external – hydraulic end position in the main valve |
|||||
HC, HD, HK, HZ, HY |
160 |
160 |
160 |
160 |
160 |
1) | If the specified flow values are exceeded, the function of the return spring is no longer guaranteed if the pilot pressure fails! |
NG10
3-spool position valves – qV max in l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring-centered |
|||||
E, J, L, M, Q, U, V, W, R |
160 |
160 |
160 |
160 |
160 |
F, P |
160 |
120 |
100 |
90 |
90 |
G, T |
160 |
160 |
160 |
130 |
120 |
H |
160 |
160 |
120 |
110 |
100 |
(measured with HLP46, ϑOil = 40 °C ±5 °C)
NG16
Δp-qV characteristic curves
Symbol |
Spool position |
Zero position |
|||||
P –A |
P – B |
A – T |
B – T |
P – T |
A – T |
B – T |
|
D, E, Y |
1 |
1 |
3 |
3 |
|||
F |
1 |
2 |
5 |
5 |
4 |
3 |
– |
G |
4 |
1 |
5 |
5 |
7 |
– |
– |
C, H |
1 |
1 |
5 |
6 |
2 |
4 |
4 |
K, J |
2 |
2 |
6 |
6 |
– |
3 |
– |
L |
2 |
2 |
5 |
4 |
– |
3 |
– |
M |
1 |
1 |
3 |
4 |
|||
P |
2 |
1 |
3 |
6 |
5 |
– |
– |
Q |
1 |
1 |
6 |
6 |
|||
R |
2 |
4 |
7 |
– |
|||
S |
3 |
3 |
3 |
– |
9 |
– |
– |
T |
4 |
1 |
5 |
5 |
7 |
– |
– |
U |
2 |
2 |
3 |
4 |
6 |
||
V, Z |
1 |
1 |
6 |
6 |
10 |
8 |
8 |
W |
1 |
1 |
3 |
4 |
Performance limits: (measured with HLP46, ϑOil = 40 °C ±5 °C)
NG16
2-spool position valve – qV maxin l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring end position in the main valve1) (with ppilot min = 12 bar) |
|||||
C, D, K, Y, Z |
300 |
300 |
300 |
300 |
300 |
X external – spring end position in the main valve |
|||||
C |
300 |
300 |
300 |
300 |
300 |
D, Y |
300 |
270 |
260 |
250 |
230 |
K |
300 |
250 |
240 |
230 |
210 |
Z |
300 |
260 |
190 |
180 |
160 |
X external – hydraulic end position in the main valve |
|||||
HC, HD, HK, HZ, HY |
300 |
300 |
300 |
300 |
300 |
1) | If the specified flow values are exceeded, the function of the return spring is no longer guaranteed if the pilot pressure fails! |
NG16
3-spool position valves – qV max in l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring-centered |
|||||
E, H, J, L, M, Q, U, W, R |
300 |
300 |
300 |
300 |
300 |
F, P |
300 |
250 |
180 |
170 |
150 |
G, T |
300 |
300 |
240 |
210 |
190 |
S |
300 |
300 |
300 |
250 |
220 |
V |
300 |
250 |
210 |
200 |
180 |
X external – pressure-centered (at minimum pilot pressure of 16 bar) |
|||||
all 1) |
300 |
300 |
300 |
300 |
300 |
1) | With symbol V, the pilot control valve is not required for flows >160 l/min. |
(measured with HLP46, ϑOil = 40 °C ±5 °C)
NG25 (type W.H 22)
Δp-qV characteristic curves
Symbol |
Spool position |
Symbol |
Zero position |
||||||
P – A |
P – B |
A – T |
B – T |
B – A |
A – T |
B – T |
P – T |
||
E, D |
2 |
2 |
3 |
5 |
– |
F |
2 |
– |
4 |
J, Q, K |
2 |
2 |
4 |
6 |
– |
G, T |
– |
– |
9 |
M, W |
1 |
1 |
3 |
5 |
– |
H |
– |
– |
3 |
H, V, C, Z |
1 |
1 |
4 |
6 |
– |
L |
7 |
– |
– |
F |
1 |
2 |
4 |
5 |
– |
U |
– |
6 |
– |
G |
3 |
4 |
5 |
6 |
– |
J |
8 |
8 |
– |
R |
1 |
2 |
2 |
– |
– |
P |
– |
4 |
6 |
L |
2 |
2 |
4 |
5 |
– |
V, Z |
– |
– |
8 |
U |
2 |
2 |
2 |
6 |
– |
||||
P |
2 |
2 |
2 |
7 |
– |
||||
T |
4 |
4 |
5 |
6 |
– |
Performance limits: (measured with HLP46, ϑOil = 40 °C ±5 °C)
NG25 (type W.H 22)
2-spool position valve – qV maxin l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring end position in the main valve (with ppilot min = 11 bar / 14 bar) |
|||||
C, D, K, Y, Z |
450 |
450 |
450 |
450 |
450 |
X external – spring end position in the main valve 1) |
|||||
C |
450 |
450 |
320 |
250 |
200 |
D, Y |
450 |
450 |
450 |
400 |
320 |
K |
450 |
215 |
150 |
120 |
100 |
Z |
350 |
300 |
290 |
260 |
160 |
X external – hydraulic end position in the main valve |
|||||
HC, HD, HK, HZ, HY |
450 |
450 |
450 |
450 |
450 |
HC./O…, HD./O…, HK./O…, HZ./O… |
450 |
450 |
450 |
450 |
450 |
HC./OF…, HD./OF…, HK./OF…, HZ./OF… |
450 |
450 |
450 |
450 |
450 |
1) | If the specified flow values are exceeded, the function of the return spring is no longer guaranteed if the pilot pressure fails! |
NG25 (type W.H 22)
3-spool position valves – qV max in l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring-centered |
|||||
E, J, L, M, Q, U, W, R |
450 |
450 |
450 |
450 |
450 |
H |
450 |
450 |
300 |
260 |
230 |
G |
400 |
350 |
250 |
200 |
180 |
F |
450 |
270 |
175 |
130 |
110 |
V |
450 |
300 |
240 |
220 |
160 |
T |
400 |
300 |
240 |
200 |
160 |
P |
450 |
270 |
180 |
170 |
110 |
(measured with HLP46, ϑOil = 40 °C ±5 °C)
NG25 (type W.H 25)
Δp-qV characteristic curves
Symbol |
Spool position |
Zero position |
|||||
P – A |
P – B |
A – T 1) |
B – T 1) |
A – T |
B – T |
P – T |
|
E, Y, D |
1 |
1 |
4 |
4 |
|||
F |
1 |
1 |
2 |
4 |
2 |
– |
5 |
G, T |
1 |
1 |
2 |
5 |
– |
– |
7 |
H |
1 |
1 |
2 |
5 |
2 |
2 |
4 |
C |
1 |
1 |
2 |
5 |
|||
J |
1 |
1 |
2 |
5 |
6 |
5 |
– |
K |
1 |
1 |
2 |
5 |
|||
L |
1 |
1 |
2 |
4 |
5 |
– |
– |
M |
1 |
1 |
3 |
4 |
|||
P |
1 |
1 |
3 |
5 |
– |
3 |
5 |
Q |
1 |
1 |
2 |
3 |
|||
R |
1 |
1 |
3 |
– |
|||
U |
1 |
1 |
2 |
5 |
– |
5 |
– |
V |
1 |
1 |
2 |
5 |
8 |
7 |
– |
Z |
1 |
1 |
2 |
5 |
|||
W |
1 |
1 |
3 |
4 |
|||
8 Symbol R, spool position B – A |
1) | The pressure differential refers to the use of port T. If port T1 is additionally used, the pressure differential maybe lower. If only port T1 is used, the relations A – T and B – T may be reversed. |
Performance limits: (measured with HLP46, ϑOil = 40 °C ±5 °C)
NG25 (type W.H 25)
2-spool position valve – qV maxin l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring end position in the main valve (with ppilotmin = 13 bar) |
|||||
C, D, K, Y, Z |
700 |
700 |
700 |
700 |
650 |
X external – spring end position in the main valve 1) |
|||||
C |
700 |
700 |
700 |
700 |
650 |
D, Y |
700 |
650 |
400 |
350 |
300 |
K |
700 |
650 |
420 |
370 |
320 |
Z |
700 |
700 |
650 |
480 |
400 |
X external – hydraulic end position in the main valve |
|||||
HC, HD, HK, HZ, HY |
700 |
700 |
700 |
700 |
700 |
HC./O…, HD./O…, HK./O…, HZ./O… |
700 |
700 |
700 |
700 |
700 |
HC./OF…, HD./OF…, HK./OF…, HZ./OF… |
700 |
700 |
700 |
700 |
700 |
1) | If the specified flow values are exceeded, the function of the return spring is no longer guaranteed if the pilot pressure fails! |
NG25 (type W.H 25)
3-spool position valves – qV max in l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring-centered |
|||||
E, L, M, Q, U, W |
700 |
700 |
700 |
700 |
650 |
G, T |
400 |
400 |
400 |
400 |
400 |
F |
650 |
550 |
430 |
330 |
300 |
H |
700 |
650 |
550 |
400 |
360 |
J |
700 |
700 |
650 |
600 |
520 |
P |
650 |
550 |
430 |
430 |
300 |
V |
650 |
550 |
400 |
350 |
310 |
R |
700 |
700 |
700 |
650 |
580 |
X external – pressure-centered (at minimum pilot pressure of 18 bar) |
|||||
E, F, H, J, L, M, P, Q, R, U, V, W |
700 |
700 |
700 |
700 |
650 |
G, T |
400 |
400 |
400 |
400 |
400 |
X external – pressure-centered (with pilot pressure > 30 bar) |
|||||
G, T |
700 |
700 |
700 |
700 |
650 |
(measured with HLP46, ϑOil = 40 °C ±5 °C)
Size 32
∆p-qv-characteristic curves – Symbol E, R and W
Symbol |
Spool position |
||||
P – A |
P – B |
A – T |
B – T |
B – A |
|
E |
4 |
4 |
3 |
2 |
– |
R |
4 |
4 |
3 |
– |
1 |
W |
4 |
4 |
3 |
2 |
– |
Size 32
∆p-qv- characteristic curves – Symbol G and T
Performance limits: (measured with HLP46, ϑOil = 40 °C ±5 °C)
Symbol |
Spool position |
||||
P – A |
P – B |
A – T |
B – T |
P – T |
|
G |
7 |
8 |
7 |
5 |
6 |
T |
7 |
8 |
7 |
5 |
6 |
Size 32
2-spool position valve – qV maxin l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring end position in the main valve (with ppilot min = 10 bar) |
|||||
C, D, K, Y, Z |
1100 |
1040 |
860 |
750 |
680 |
X external – spring end position in the main valve 1) |
|||||
C |
1100 |
1040 |
860 |
800 |
700 |
D, Y |
1100 |
1040 |
540 |
480 |
420 |
K |
1100 |
1040 |
860 |
500 |
450 |
Z |
1100 |
1040 |
860 |
700 |
650 |
X external – hydraulic end position in the main valve |
|||||
HC, HD, HK, HZ, HY |
1100 |
1040 |
860 |
750 |
680 |
1) | If the specified flow values are exceeded, the function of the return spring is no longer guaranteed if the pilot pressure fails! |
Size 32
3-spool position valves – qV max in l/min |
|||||
Symbol |
Operating pressure pmax in bar |
||||
70 |
140 |
210 |
280 |
350 |
|
X external – spring-centered |
|||||
E, J, L, M, Q, R, U, W |
1100 |
1040 |
860 |
750 |
680 |
G, T, H, F, P |
900 |
900 |
800 |
650 |
450 |
V |
1100 |
1000 |
680 |
500 |
450 |
X external – pressure-centered (at minimum pilot pressure of 8.5 bar) |
|||||
all |
1100 |
1040 |
860 |
750 |
680 |
2 spool positions
1) | Only for NG10 and 25 ("H-WEH 22") with 3/2-way version; if operating pressure > tank pressure, port T is to be used as a leakage port! |
Ordering code |
Type of actuation |
|
Symbol |
Spool return |
Type H-WH (hydraulic) |
A 1), C, D, K, Z |
../.. |
|
..H../.. |
||
B 1),Y |
../.. |
3 spool positions
2)Example: Symbol E with actuating side "a" → ordering code ..EA.. | |
3) Symbol S only for NG16 |
Ordering code |
Type of actuation |
||
Symbol |
Actuating side |
Spool return |
Type H-WH (hydraulic) |
E, F, G, H, J, L, M, Q, R, S, T, U, V, W |
../.. |
||
..H../.. |
Inductive position switch type QM Switching logics
Version QMA
(Position switch on side B, monitored spool position of the main stage "a")
Version QMA
(Position switch on side B, monitored spool position of the main stage "a")
Version QMB
(Position switch on side A, monitored spool position of the main stage "b")
Version QMB
(Position switch on side A, monitored spool position of the main stage "b")
version QMAB
(Position switch on side A and B, monitored spool position "a" and "b")
Version QM0
(Position switch on side A and B, monitored spool position "0")
1) No signal change at the position switch on side B with spool position "a" | |
2) No signal change at the position switch on side A with spool position "b" |
Version QM0
(Position switch on side B, monitored spool position of the main stage "0")
Version QM0
(Position switch on side A, monitored spool position of the main stage "0")
NG10
Dimensions in mm
Required surface quality of the valve contact surface |
Notice:
The dimensions are nominal dimensions which are subject to tolerances.
1 |
Main valve |
7 |
Height of the diversion plate with hydraulic actuation |
10.1 |
machined valve contact surface; porting pattern according to ISO 4401-05-05-0-05 |
12 |
Name plate complete valve |
13 |
Seal rings |
NG16
Dimensions in mm
Required surface quality of the valve contact surface |
Notice:
The dimensions are nominal dimensions which are subject to tolerances.
1 |
Main valve |
7 |
Height of the diversion plate with hydraulic actuation |
10.2 |
machined valve contact surface; porting pattern according to ISO 4401-07-07-0-05 |
12 |
Name plate complete valve |
13 |
Seal rings |
15 |
2-spool position valves with spring end position in the main valve (spool symbols A, C, D, K, Z) |
16 |
2-spool position valves with spring end position in the main valve (spool symbols B, Y) |
17 |
3-spool position valves, spring-centered; |
19 |
Locking pin |
NG25 (type W.H 22)
Dimensions in mm
1) | Port L only for valves with pressure-centered zero position |
Required surface quality of the valve contact surface |
Notice:
The dimensions are nominal dimensions which are subject to tolerances.
1 |
Main valve |
7 |
Height of the diversion plate with hydraulic actuation |
10.3 |
machined valve contact surface; porting pattern according to ISO 4401-08-08-0-05 |
12 |
Name plate complete valve |
13 |
Seal rings |
19 |
Locking pin |
NG25 (type W.H 25)
Dimensions in mm
1) | Port L only for valves with pressure-centered zero position |
Required surface quality of the valve contact surface |
Notice:
The dimensions are nominal dimensions which are subject to tolerances.
1 |
Main valve |
7 |
Height of the diversion plate with hydraulic actuation |
10.3 |
machined valve contact surface; porting pattern according to ISO 4401-08-08-0-05 |
12 |
Name plate complete valve |
13 |
Seal rings |
15 |
2-spool position valves with spring end position in the main valve (spool symbols A, C, D, K, Z) |
16 |
2-spool position valves with spring end position in the main valve (spool symbols B, Y) |
17 |
3-spool position valves, spring-centered; |
18 |
3-spool position valve, pressure-centered |
19 |
Locking pin |
Size 32
Dimensions in mm
Required surface quality of the valve contact surface |
Notice:
The dimensions are nominal dimensions which are subject to tolerances.
1 |
Main valve |
7 |
Height of the diversion plate with hydraulic actuation |
10.4 |
machined valve contact surface; porting pattern according to ISO 4401-10-09-0-05 |
12 |
Name plate complete valve |
13 |
Seal rings |
15 |
2-spool position valves with spring end position in the main valve (spool symbols A, C, D, K, Z) |
16 |
2-spool position valves with spring end position in the main valve (spool symbols B, Y) |
17 |
3-spool position valves, spring-centered; |
18 |
3-spool position valve, pressure-centered |
19 |
Locking pin |
Subplates (separate order) with porting pattern according to ISO 4401 see data sheet 45100.
Valve mounting screws (separate order)
– NG10:
4 metric hexagon socket head cap screws
ISO 4762 - M6 x 45 - 10.9-flZn-240h-L
(friction coefficientμtotal = 0.09 to 0.14);
tightening torque M A = 12.5 Nm ± 10%,
material no. R913000258
4 hexagon socket head cap screws UNC
1/4-20 UNC x 1 3/4″ ASTM-A574
on request
– NG16:
4 metric hexagon socket head cap screws
ISO 4762 - M10 x 60 - 10.9-flZn-240h-L
(friction coefficientμtotal = 0.09 to 0.14);
tightening torque MA = 75 Nm ± 10%,
material no. R913000116
2 metric hexagon socket head cap screws
ISO 4762 - M6 x 60 - 10.9-flZn-240h-L
(friction coefficient μtotal = 0.09 to 0.14);
tightening torque MA = 12.5 Nm ± 10%,
material no. R913000115
4 hexagon socket head cap screws UNC3/8-16 UNC x 2 1/4″ ASTM-A574
on request
2 hexagon socket head cap screws UNC1/4-20 UNC x 1/4″ ASTM-A574
on request
– NG25:
6 metric hexagon socket head cap screws
ISO 4762 - M12 x 60 - 10.9-flZn-240h-L
(friction coefficient μtotal = 0.09 to 0.14);
tightening torque MA = 130 Nm ± 10%,
material no. R913000121
6 hexagon socket head cap screws UNC 1/2-13 UNC x 2 1/2″ ASTM-A574
on request
– NG32:
6 metric hexagon socket head cap screws
ISO 4762 - M20 x 80 - 10.9-flZn-240h-L
(friction coefficient μtotal = 0.09 to 0.14);
tightening torqueMA = 430 Nm ± 10%,
material no. R901035246
6 hexagon socket head cap screws UNC 3/4-10 UNC x 3 1/4″ ASTM-A574
on request
Stroke setting, mounting options
The stroke of the control spool is limited by the stroke setting (1). The control spool stroke is shortened by loosening the lock nut (2) and clockwise rotation of the adjustment spindle (3). The control chamber (4) must be depressurized for this.
NG |
L4 |
mm |
|
10 | 6.5 |
16 | 10 |
25 (H-WH22) | 9.5 |
25 (H-WH25) | 12.5 |
32 | 15 |
5 adjustment range
– NG10:
1 rotation = 1 mm adjustment travel
– NG16 to 32:
1 rotation = 1.5 mm adjustment travel
Stroke setting, mounting options
Stroke limitation on side A
Stroke setting, mounting options
Stroke limitation on side B
Mounting options |
Ordering code |
NG |
3-spool position valve 1) |
|||||
Spring-centered |
Pressure-centered |
|||||||
L1 (mm) |
L2 (mm) |
L3 (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
|||
Stroke setting on valve side A and B |
10 |
10 |
90 |
144 |
234 |
|||
16 |
100 |
200 |
300 |
|||||
25 2) |
96 |
241 |
337 |
|||||
25 3) |
123 |
276 |
399 |
|||||
32 |
133 |
344 |
477 |
|||||
Stroke setting on valve side A |
11 |
10 |
90 |
106 |
196 |
|||
16 |
100 |
156 |
256 |
|||||
25 2) |
96 |
193 |
289 |
|||||
25 3) |
123 |
225 |
348 |
|||||
32 |
133 |
287 |
420 |
|||||
Stroke setting on valve side B |
12 |
10 |
52 |
144 |
196 |
– |
– |
– |
16 |
56 |
200 |
256 |
81 |
200 |
281 |
||
25 2) |
48 |
241 |
289 |
– |
– |
– |
||
25 3) |
72 |
276 |
348 |
107 |
276 |
283 |
||
32 |
76 |
344 |
420 |
120 |
344 |
464 |
1) With symbol A only version "11", with symbol B only version "12" possible. |
2-spool position valve |
|||||||||||
Spring end position |
Hydraulic end position |
||||||||||
A, C, D, K, Z |
B, Y |
HC, HD, HK, HZ, HY |
|||||||||
Mounting options |
Ordering code |
NG |
L1 (mm) |
L2 (mm) |
L3 (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
Stroke setting on valve side A and B |
10 |
10 |
90 |
144 |
234 |
90 |
144 |
234 |
90 |
144 |
234 |
16 |
– |
– |
– |
– |
– |
– |
100 |
200 |
300 |
||
25 1) |
96 |
241 |
337 |
96 |
241 |
337 |
96 |
241 |
337 |
||
25 2) |
– |
– |
– |
– |
– |
– |
123 |
276 |
399 |
||
32 |
– |
– |
– |
– |
– |
– |
133 |
344 |
477 |
||
Stroke setting on valve side A |
11 |
10 |
90 |
106 |
196 |
– |
– |
– |
90 |
106 |
196 |
16 |
100 |
180 |
280 |
– |
– |
– |
100 |
156 |
256 |
||
25 1) |
96 |
193 |
289 |
96 |
193 |
289 |
96 |
193 |
289 |
||
25 2) |
123 |
253 |
376 |
– |
– |
– |
123 |
225 |
348 |
||
32 |
133 |
316 |
449 |
– |
– |
– |
133 |
287 |
420 |
||
Stroke setting on valve side B |
12 |
10 |
52 |
144 |
196 |
52 |
144 |
196 |
52 |
144 |
196 |
16 |
– |
– |
– |
80 |
200 |
280 |
56 |
200 |
256 |
||
25 1) |
48 |
241 |
289 |
48 |
241 |
289 |
48 |
241 |
289 |
||
25 2) |
– |
– |
– |
100 |
276 |
376 |
72 |
276 |
348 |
||
32 |
– |
– |
– |
105 |
344 |
449 |
76 |
344 |
420 |
1) Version "H-WH 22" | |
2) Version "H-WH 25" |
Spool position monitoring
Inductive position switch type QM
Dimensions in mm
1) | Without mating connector |
Notice:
The dimensions are nominal dimensions which are subject to tolerances.
Mounting options – 2-spool position valve |
||||||||||||||
Monitored spool position |
Ordering code |
NG |
Hydraulic end position HC, HD, HK, HZ |
Spring end position C, D, K, Z |
Spring end position Y |
|||||||||
L1 (mm) 1) |
L2 (mm) 1) |
L3 (mm) |
L4 (mm) |
L1 (mm) 1) |
L2 (mm) 1) |
L3 (mm) |
L4 (mm) |
L1 (mm) 1) |
L2 (mm) 1) |
L3 (mm) |
L4 (mm) |
|||
„a“ Position switch on side B |
QMAG24 |
10 |
211 |
57 |
211 |
57 |
211 |
57 |
||||||
16 |
259 |
55 |
259 |
55 |
||||||||||
25 2) |
294 |
47 |
294 |
47 |
294 |
47 |
||||||||
25 3) |
325 |
72 |
325 |
72 |
||||||||||
32 |
371 |
76 |
371 |
76 |
||||||||||
„b“ Position switch on side A |
QMBG24 |
10 |
157 |
111 |
157 |
111 |
157 |
111 |
||||||
16 |
159 |
155 |
159 |
155 |
||||||||||
25 2) |
149 |
192 |
149 |
192 |
149 |
192 |
||||||||
25 3) |
172 |
225 |
172 |
225 |
||||||||||
32 |
161 |
287 |
161 |
287 |
||||||||||
"a" and "b" Position switch on side A and B |
QMABG24 |
10 |
157 |
211 |
157 |
211 |
157 |
211 |
||||||
16 |
159 |
259 |
||||||||||||
25 2) |
149 |
294 |
149 |
294 |
149 |
294 |
||||||||
25 3) |
172 |
325 |
||||||||||||
32 |
161 |
371 |
1) Without mating connector | |
2) Type 4W.H 22.. | |
3) Type 4W.H 25.. |
Mounting options – 3-spool position valve |
||||||||||
Monitored spool position |
Ordering code |
NG |
Spring-centered |
Pressure-centered |
||||||
L1 (mm) 1) |
L2 (mm) 1) |
L3 (mm) |
L4 (mm) |
L1 (mm) 1) |
L2 (mm) 1) |
L3 (mm) |
L4 (mm) |
|||
„a“ Position switch on side B |
QMAG24 |
10 |
211 |
57 |
||||||
16 |
259 |
55 |
259 |
81 |
||||||
25 2) |
294 |
47 |
||||||||
25 3) |
325 |
72 |
325 |
107 |
||||||
32 |
371 |
76 |
371 |
120 |
||||||
„b“ Position switch on side A |
QMBG24 |
10 |
157 |
111 |
||||||
16 |
159 |
155 |
||||||||
25 2) |
149 |
192 |
||||||||
25 3) |
172 |
225 |
||||||||
32 |
161 |
287 |
||||||||
"a" and "b" Position switch on side A and B |
QMABG24 |
10 |
157 |
211 |
||||||
16 |
159 |
259 |
||||||||
25 2) |
149 |
294 |
||||||||
25 3) |
172 |
325 |
||||||||
32 |
161 |
371 |
||||||||
Zero position Position switch on side A and B 2 position switches |
QM0G24 4) |
10 |
157 |
211 |
||||||
16 |
159 |
259 |
||||||||
25 2) |
149 |
294 |
||||||||
25 3) |
172 |
325 |
||||||||
32 |
161 |
371 |
1) Without mating connector | |
2) Type 4W.H 22 | |
3) Type 4W.H 25 | |
4) 3-spool position valve | |
Mounting options – 3-spool position valve with one solenoid |
||||||||||||||
Monitored spool position |
Ordering code |
NG |
Side A (EA, FA…) Spring-centered |
Solenoids on side B (EB, FB…) Spring-centered |
Side A (EA, FA…) Pressure-centered |
|||||||||
L1 (mm) 1) |
L2 (mm) 1) |
L3 (mm) |
L4 (mm) |
L1 (mm) 1) |
L2 (mm) 1) |
L3 (mm) |
L4 (mm) |
L1 (mm) 1) |
L2 (mm) 1) |
L3 (mm) |
L4 (mm) |
|||
„a“ Position switch on side B |
QMAG24 |
10 |
211 |
57 |
||||||||||
16 |
259 |
55 |
259 |
81 |
||||||||||
25 2) |
294 |
47 |
||||||||||||
25 3) |
325 |
72 |
325 |
107 |
||||||||||
32 |
371 |
371 |
120 |
|||||||||||
„b“ Position switch on side A |
QMBG24 |
10 |
157 |
111 |
||||||||||
16 |
159 |
155 |
||||||||||||
25 2) |
149 |
192 |
||||||||||||
25 3) |
172 |
225 |
||||||||||||
32 |
161 |
287 |
||||||||||||
Zero position Position switch on side A or B 1 position switches |
QM0G24 4) |
10 |
211 |
57 |
157 |
111 |
||||||||
16 |
259 |
55 |
159 |
155 |
259 |
81 |
||||||||
25 2) |
294 |
47 |
149 |
192 |
||||||||||
25 3) |
325 |
72 |
172 |
225 |
325 |
107 |
||||||||
32 |
371 |
76 |
161 |
287 |
371 |
120 |
1) Without mating connector | |
2) Type 4W.H 22.. | |
3) Type 4W.H 25.. | |
4) 2-spool position valve | |
Switching time adjustment
Type 4WEH 10 ..4X/…S
Type 4WEH 10 ..4X/…S2The switching time of the main valve (1) is influenced by using a twin throttle check valve (2) (type Z2FS 6; data sheet 27506).
Modification of supply (3) to discharge control (4):
Remove the pilot control valve (5) – The plate (6) to accept the seal rings stays in place – Turn the switching time adjustment (2) around its longitudinal axis and put it back, install the pilot control valve (5).
Notice:
The modification may only be performed by authorized specialists or at the factory!
"D3” pressure reducing valve
Type 4WEH 10 ..4X/…/..D3
The pressure reducing valve (8) has to be used at a pilot pressure above 250 bar (with type 4WEH 22 …: 210 bar) and with version “H”.
The secondary pressure is kept at a constant level of 45 bar.
Notice:
If a pressure reducing valve "D3" (8) is used, a "B10" throttle insert has to be installed in channel P of the pilot control valve. The modification may only be performed by authorized specialists or at the factory!The stipulations of the Machinery Directive 2006/42/EC are to be adhered to! Please also note data sheet 08012 with information on MTTFd values and shock and vibration loads!
