HYDAC
3046161
$131.86 USD
- HYDAC
- Material:3046161
- Model:WK10G-01-C-N-0
- Summary:WK10G-01-C-N-0 Without Coil
Due to extremely high demand, please call 920-337-0234 for availability
The solenoid-actuated 4/3 directional spool valve WK10G is a direct acting cartridge valve with two coils. In de-energized mode it permits a flow from port 3 to 1 while ports 2 and 4 are blocked. When energizing the one or the other coil either a parallel or a crosswise flow is achieved. Cavity UNF 7/8-14. Qmax = 23 l/min Pmax = 350 bar
