HYDAC
3049276
$137.11 USD
- HYDAC
- Material:3049276
- Model:WS16Y-01-C-N-0WITHOUTCOIL
- Summary:WS16Y-01-C-N-0 WITHOUT COIL
Due to extremely high demand, please call 920-337-0234 for availability
The solenoid-actuated 2/2 directional poppet valve WS16Y is a pilot operated cartridge valve. In de-energized mode it permits flow from port 2 to 1. When energized flow is blocked from port 2 to 1. In the opposite direction there is free flow possible. Cavity UNF 1 5/16-12. Qmax = 150 l/min Pmax = 350 bar
