HYDRAFORCE
5009192

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SV08-31M-0-N-24DG (5009192) is a high-performance, solenoid-operated, 3-port, direct-acting, spool-type hydraulic directional valve. This compact and efficient unit is designed for screw-in installation and is notable for its hardened precision spool and cage which ensure long life and reliability under continuous duty. The valve operates by allowing flow from port 1 to port 2 when deenergized, and shifts to allow flow from port 3 to port 1 while blocking port 2 when energized. Key features of the SV08-31M-0-N-24DG include a unitized, molded coil design, optional manual override, and the availability of waterproof E-Coils rated up to IP69K. The valve's cartridges are voltage interchangeable which provides flexibility in usage across different systems with varying voltage requirements. All ports on this valve can be fully pressurized which enhances its application in various hydraulic systems. The valve is designed for use with mineral-based or synthetic hydraulic fluids with lubricating properties and can operate within a fluid viscosity range of 7.4 to 420 cSt. It supports an operating fluid temperature range from -40°C to +100°C with Buna N seals, enhancing its versatility in different environmental conditions. Additionally, the SV08-31M-0-N-24DG can handle pressures up to 207 bar (3000 psi) with proof pressure at 241 bar (3500 psi) and a burst pressure rating of 620 bar (9000 psi). Overall, the Hydraforce SV08-31M-0-N-24DG offers robust performance for controlling fluid flow in hydraulic systems, making it suitable for a wide range of applications requiring precise control and reliability.
