HYDRAFORCE
5010834

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5010834 (5010834) is a solenoid-operated, 2-way, piloted, poppet-type, normally open hydraulic cartridge valve specifically designed for low leakage in high-pressure load-holding applications. This valve functions by allowing flow from port 2 to port 1 when de-energized; however, flow from port 1 to port 2 is significantly restricted under these conditions. Upon energization, the valve's poppet closes tightly against its seat to block any flow from port 2 to port 1 entirely. For reverse flow from port 1 to port 2, the solenoid must be overcome with a pressure range of 50 to 150 psi (3.4 to 10.3 bar). Key features of this model include a continuous-duty rated coil and corrosion-resistant plating which enhance durability and performance longevity in various environments. The hardened seat ensures both prolonged life and minimal leakage over time. The unit also offers flexibility in terms of customization with optional coil voltages and terminations available. Moreover, the cartridges are voltage interchangeable which provides additional adaptability for various system requirements. The Hydraforce 5010834 also boasts a unitized, molded coil design that aids in robust operation and easy installation. A manual override option is available for increased control during operation or maintenance processes. Additionally, optional waterproof E-Coils are offered for this model, which are rated up to IP69K for optimal protection against dust and moisture ingress. This compact-sized valve aligns with industry common dimensions making it suitable for integration into diverse hydraulic systems without requiring extensive modifications or special accommodations.
